Name: SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission
Brand: Shenzhen HiLink Technology Co.,Ltd.
SKU: HL-SFP-BXU-L5/HL-SFP-BXD-L5
Price: 5.00 USD
Availability: InStock

Zu Hause > produits > Optisches Transceivermodul >

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission

Herkunftsort:

Markenname:

HiLink or OEM

Zertifizierung:

CE FCC ROSH

Modellnummer:

HL-SFP-BXU-L5/HL-SFP-BXD-L5

Kontakt mit uns

Bitte um ein Angebot

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission

Einzelheiten zum Produkt

Produktname:

SFP+ 10G BIDI 5KM optischer Transceiver

Datengeschwindigkeit:

10g

Übertragung:

5 km

Steckertyp:

Wellenlänge:

T1270/R1330

Kompatibel:

Cisco, Juniper, Arista, Huawei usw

Zahlungs- und Versandbedingungen

Min Bestellmenge

1 Paar

Preis

US$5.00~US$6.00/pair

Verpackung Informationen

Normales Paket oder OEM

Lieferzeit

5-8 Werktage

Zahlungsbedingungen

T/T, Paypal, Western Union

Versorgungsmaterial-Fähigkeit

2000 Paare pro Woche

Verwandte Produkte

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission

Erhalten Sie besten Preis

10Gb/s XFP Bi-direktionaler Transceiver 40km Reichweite TX1270/1330nm RX1330/1270nm RoHS-konform

Erhalten Sie besten Preis

Hilink 10G Datenrate SFP+ Transceiver mit 30M/80M Abstand und RoHS-konformem Kupfermodul 10GBASE-T

Erhalten Sie besten Preis

Hilink HL-SFP-T 1000BASE-T und 10/100/1000BASE-T Kupfer-SFP-Transceiver mit RJ-45-Anschluss

Erhalten Sie besten Preis

Kontakt mit uns

Kontaktieren Sie uns jetzt

Beschreibung des Produkts

Description

The HL-SFP-BXU-L5/HL-SFP-BXD-L5 Transceiver is intended for 5km reach service from 0.6Gb/s to 10.3125Gb/s BI-direction single mode high-speed communications equipment where low-cost, extraordinary performance and reliability are essential. It consumes low power, operates base on 3.3V DC power supply and is offered in the industrial temperature range. They are compliant with SFP28 MSA, SFF-8431 and SFF-8432.

The low jitter and low bit error rate optical assembly features a DML laser transmitter and PIN/TIA receiver. The differential AC coupled Tx and Rx data interfaces are CML compatible. The device is Class I laser safety compliant.

Product features

l Operating data rate up to 10.3125Gbps

l Up to 5km transmission distance

l High sensitivity PIN photodiode and TIA

l 12dB Power Budget at Least

l LC single connector

l Hot pluggable 20pin connector

l Low power consumption <1.2 W

l Single +3.3V±5% power supply

l Compliant with SFF-8472&SFF-8431

l Fully RoHS Compliant

l Compliant with IEEE802.3ae 10GBASE-LR/LW

l Operating temperature range:

Commercial: 0°C to +70°C

Industrial: -40°C to +85°C

Application

l 10GBASE-LR at 10.31Gbps

l 10GBASE-LW at 9.95Gbps

l Other Optical Links

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission 0

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission 1

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission 2
